Toyota Sienna Service Manual: Air fuel ratio sensor (for 2wd)

Toyota Sienna Service Manual / Engine / 2Gr-fe emission control / Air fuel ratio sensor (for 2wd)

Components

Components

Installation
1. INSTALL VENTILATION VALVE (a) Install the ventilation valve. (1) Apply adhesive to 2 or 3 threads. Adhesive: Part No. 08833-00070, Three Bond 1324 or equivalent (2) Install the vent ...

On-vehicle inspection
HINT: The type of ignition switch on this model differs according to the specifications of the vehicle. For the expressions used in this section, refer to the "EXPRESSIONS OF IGNITION SWITCH& ...
