Toyota Sienna. Door pockets


Toyota Sienna. Door pockets



NOTICE Rear: Make sure magazines are not bent or protruding from the sliding door pockets.

Do not insert anything too big so that the shape of the sliding door pockets is distorted. Such objects may obstruct the opening/closing of the sliding doors, damage the sliding door pockets or the vehicle body, and may result in a malfunction.

Toyota Sienna. Door pockets

Bottle holders
Front Rear When storing a bottle, close the cap. The bottle may not be stored depending on its size or shape. WARNING Do not place anything other than a bottle in ...

Auxiliary boxes
Type A Push the lid. Type B Push down the knob. Type C (if equipped) Type D Type E (if equipped) Type F Lift the lid. Type G (if equip ...
