Toyota Sienna Service Manual: Engine coolant temperature sensor

Toyota Sienna Service Manual / 2GR-FE Engine control system / Engine coolant temperature sensor

COMPONENTS

COMPONENTS

Installation
1. INSTALL CRANKSHAFT POSITION SENSOR  Apply a light coat of engine oil to the O-ring on the crankshaft position sensor.  Install the crankshaft position sensor with the bolt. ...

Removal
1. DRAIN ENGINE COOLANT 2. REMOVE V-BANK COVER SUB-ASSEMBLY 3. REMOVE NO. 2 AIR CLEANER INLET 4. REMOVE NO. 1 AIR CLEANER INLET 5. REMOVE AIR CLEANER CAP SUB-ASSEMBLY 6. REMOVE AIR CLEANER CASE S ...
