Toyota Sienna Service Manual: On-vehicle inspection

1. CHECK VVT SENSOR OUTPUT VOLTAGE

CHECK VVT SENSOR OUTPUT VOLTAGE

  1. Turn the ignition switch to the ON position.
  2. Check the voltage between the specified terminal and body ground.

Standard voltage

Standard voltage

  1. While turning the crankshaft pulley by hand, measure the voltage between each terminal. Check that the voltage changes between the High range and Low range shown in the table below.

Standard voltage

Standard voltage

VVT sensor
COMPONENTS ...
