BMW 3 Series 2018-2023 Owners Manual: DTC Dynamic Traction Control

BMW 3 Series 2018-2023 Owners Manual / Driving stability control systems / DTC Dynamic Traction Control

Concept

DTC is a version of the DSC Dynamic Stability Control where forward momentum is optimized.

The system ensures maximum headway on special road conditions or loose road surfaces, for instance unplowed snowy roads, but with somewhat limited driving stability.

General information

When DTC is activated, the vehicle has maximum traction. Driving stability is limited during acceleration and when driving in curves.

You may find it useful to briefly activate DTC in the following situations:

When driving in slush or on uncleared, snow-covered roads.
When driving off from deep snow or loose ground.
When driving with snow chains.

Overview

Button in the vehicle

Driving stability control systems

DSC OFF

Activating/deactivating DTC

Activating DTC

Press the button.

TRACTION is displayed in the instrument cluster and the indicator light for DSC OFF lights up.

Deactivating DTC

Press the button again.

TRACTION and the DSC OFF indicator light go out.

Display

Display in the instrument cluster

If DTC is activated, TRACTION is displayed in the instrument cluster.

Indicator/warning lights

The indicator light lights up: DTC is activated.

Automatic program change

In certain situations, the DSC is activated automatically:

If Active Cruise Control with Stop&Go function ACC is activated.
On a braking intervention by the Intelligent Safety systems.
The vehicle has a flat tire.

DSC Dynamic Stability Control

Concept Within the physical limits, the system helps to keep the vehicle on a steady course by reducing engine speed and by braking the individual wheels. General information DSC detects the following ...

xDrive

Concept xDrive is the all-wheel-drive system of the vehicle. The interaction of xDrive and other suspension control systems, such as DSC Dynamic Stability Control, further optimizes traction and driv ...
