Toyota Sienna Service Manual: Air conditioning unit

COMPONENTS

Air conditioning unit

Air conditioning unit

Air conditioning unit

Air conditioning unit

Air conditioning unit

Air conditioning unit

Air conditioning unit

Replacement
1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM SST 07110-58060 (07117-58080, 07117-58090, 07117-78050, 07117-88060, 07117-88070, 07117-88080) (a) Turn the A/C switch to ON. (b) Operating t ...

Removal
1. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM (See page AC-172) 2. REMOVE FRONT WIPER ARM HEAD CAP (See page WW-4) 3. REMOVE FRONT WIPER ARM RH (See page WW-4) 4. REMOVE FRONT WIPER ARM LH (Se ...

Other materials:

CD Player Mechanical Error/ CD Insertion and Ejection Error/ CD Reading Abnormal/ CD Changer Mechanical Error/ CD Insertion and Ejection Error/ CD Reading Abnormal
DTC 62-10 CD Player Mechanical Error DTC 62-11 CD Insertion and Ejection Error DTC 62-12 CD Reading Abnormal DTC 63-10 CD Changer Mechanical Error DTC 63-11 CD Insertion and Ejection Error DTC 63-12 CD Reading Abnormal DESCRIPTION DTC No. DTC Detecting Condition Troub ...

Actuator check
1. ACTUATOR CHECK (a) After entering the DTC check mode (Sensor Check Mode), press the R/F switch. (b) As each damper, motor and relay automatically operate actuator check at 1-second intervals from step No. 1 to No. 10 continuously, check the temperature and air flow visually and by hand. ...

Refrigerant
On-vehicle inspection 1. INSPECT REFRIGERANT PRESSURE WITH MANIFOLD GAUGE SET (a) This method uses a manifold gauge set to locate problem areas. Read the manifold gauge pressure when these conditions are established. Test conditions: Temperature at the air inlet is 30 to 35°C (86 to 95 ...
