Removal
1. DRAIN ENGINE COOLANT
2. REMOVE V-BANK COVER SUB-ASSEMBLY
3. REMOVE NO. 2 AIR CLEANER INLET
4. REMOVE NO. 1 AIR CLEANER INLET
5. REMOVE AIR CLEANER CAP SUB-ASSEMBLY
6. REMOVE AIR CLEANER CASE SUB-ASSEMBLY
7. REMOVE ENGINE COOLANT TEMPERATURE SENSOR
Remove the engine coolant tem ...
For rear air conditioning system
ON-VEHICLE INSPECTION
1. INSPECT REAR AIR MIX CONTROL SERVO MOTOR
(a) Inspect servo motor operation.
(1) Connect the positive (+) lead from the battery
to terminal 4 and negative (-) lead to terminal 5,
then check that the arm turns to "HOT" side
smoothly.
(2) Connect the po ...
Terminals of ecm
1. Ecm
Hint:
each ecm terminal's standard voltage is shown in the
table below.
In the table, first follow the information under "condition".
Look under "symbols (terminal no.)" For the terminals to
inspected. The standard voltage between the terminals
is shown under ...
